Stainless Steel Recycling Bin with Rotating Lids

The SRB-130 stainless steel recycling bin is produced in 2-, 3-, 4-, and 5-compartment configurations, all sharing a 35 cm depth and 80 cm height. Length scales with compartment count from 68 cm to 138 cm. The body is fabricated from AISI 304 stainless steel. Each compartment is fitted with a rotating lid that pivots through 360 degrees over the opening.

The SRB-130 is a freestanding rectangular recycling unit with a flat horizontal top and individual rotating lids per compartment. The front face carries full-height color-coded panels with waste category pictograms and bilingual labels for paper, glass, plastic, and metal streams.

Rotating-Lid Recycling Unit Configurations and Materials

Compartment Variants

The SRB-130 is offered in four configurations: 2 compartments (68 cm length), 3 compartments (92 cm), 4 compartments (115 cm), and 5 compartments (138 cm). Depth and height remain fixed at 35 cm and 80 cm across all variants.

Material Construction

The outer housing is fabricated from AISI 304 stainless steel. The body is a rectangular form with squared corners and a flat horizontal top surface. The rotating lids are produced in matching 304 stainless steel.

Rotating Lid Mechanism

Each compartment is fitted with a rotating lid mounted on a pivot axis spanning the opening. The lid rotates fully through 360 degrees, allowing waste to be deposited from either direction and returning to the resting position after release.

Construction Specifications

All structural joints are welded, with weld seams ground smooth and edges deburred. Mobility wheels are available for any configuration, and color is matched per project to any RAL code. Dimensions outside the standard table can be produced when project drawings are supplied. Production is project-based; retail sales are not offered.
