The SRB-268 304 stainless steel modular recycling bin set is produced in 2-, 3-, 4-, and 5-compartment configurations, all sharing a 35 cm depth and 80 cm height. Length scales with compartment count from 70 cm to 175 cm. The outer housing is fabricated from AISI 304 stainless steel. Each module carries a round top opening on a color-coded upper panel keyed to its waste category. The product carries a registered design certification.
The SRB-268 is a freestanding recycling unit composed of individual rectangular bin modules arranged side by side. Each module operates as a separate compartment with its own top opening and front graphic panel. Color is matched per project to any RAL code for the panels and graphics.
304 Stainless Steel Modular Recycling Set Configurations
Compartment Variants
The SRB-268 is offered in four configurations: 2 compartments (70 cm length), 3 compartments (105 cm), 4 compartments (140 cm), and 5 compartments (175 cm). Depth and height remain fixed at 35 cm and 80 cm across all variants.
Material Construction
The outer housing, top cap, and structural elements are fabricated from AISI 304 stainless steel. The upper panel and front graphic panel of each module are finished in color-coded RAL codes keyed to the corresponding waste category, configured per project on order.
Top Openings and Front Graphic Panels
Each compartment carries a round top opening on the upper panel surface, sized for its assigned waste category. The front face is finished with a full-height color-coded graphic panel carrying the waste category pictogram and bilingual label, matched to the upper panel color of the corresponding module.
Design Registration and Construction Specifications
The SRB-268 carries a registered design certification. All structural joints are welded, with weld seams ground smooth and edges deburred. Each bin module is produced as an individual welded body and supplied as a matched set. The unit sits directly on the ground without flange or anchoring hardware. Production is project-based; retail sales are not offered.
| Code | Compartments | Depth | Length | Height | Volume (L) |
|---|---|---|---|---|---|
| SRB-268-2 | 2 | 35 cm | 70 cm | 80 cm | 196.00 |
| SRB-268-3 | 3 | 35 cm | 105 cm | 80 cm | 294.00 |
| SRB-268-4 | 4 | 35 cm | 140 cm | 80 cm | 392.00 |
| SRB-268-5 | 5 | 35 cm | 175 cm | 80 cm | 490.00 |
