The SRB-125 stainless steel recycling bin is produced in 2-, 3-, 4-, and 5-compartment configurations, all sharing a 35 cm depth and 80 cm height. Length scales with compartment count from 62 cm to 146 cm. Standard production uses AISI 304 stainless steel for the outer housing with galvanized steel inner buckets; DKP cold-rolled steel with electrostatic powder coating is offered as an alternate construction. Each compartment carries a round top opening fitted with a colored ring insert keyed to its waste category.
The SRB-125 is a freestanding recycling unit with a rectangular body and a flat upper section carrying individual round openings per compartment. Each opening is framed by a colored rim — yellow, blue, green, and additional colors per project — with full-height color-coded panels on the front face. Mobility wheels are fitted to the base, and color is matched per project to any RAL code.
Color-Coded Recycling Unit Configurations and Materials
Compartment Variants
The SRB-125 is offered in four configurations: 2 compartments (62 cm length), 3 compartments (90 cm), 4 compartments (118 cm), and 5 compartments (146 cm). Depth and height remain fixed at 35 cm and 80 cm across all variants.
Material Construction
The standard outer housing is fabricated from AISI 304 stainless steel with galvanized steel inner liner buckets. As an alternate, the housing can be produced from DKP cold-rolled steel with electrostatic powder coating in any RAL color specified per project.
Round Top Openings and Color-Coded Rings
Each compartment carries a round top opening fitted with a colored ring insert. Standard ring colors include yellow, blue, green, and black, with additional colors produced per project. The front face is fitted with full-height color-coded graphic panels carrying the waste category pictogram and bilingual label, matching the ring color of the corresponding compartment.
Construction Specifications
All structural joints are welded, with weld seams ground smooth and edges deburred. Mobility wheels are fitted to the base, allowing the unit to be repositioned without lifting. Dimensions outside the standard table can be produced when project drawings are supplied. Production is project-based; retail sales are not offered.
| Code | Compartments | Depth | Length | Height | Volume (L) |
|---|---|---|---|---|---|
| SRB-125-2 | 2 | 35 cm | 62 cm | 80 cm | 174.00 |
| SRB-125-3 | 3 | 35 cm | 90 cm | 80 cm | 252.00 |
| SRB-125-4 | 4 | 35 cm | 118 cm | 80 cm | 331.00 |
| SRB-125-5 | 5 | 35 cm | 146 cm | 80 cm | 409.00 |
