Powder-Coated Recycling Bin with Rotating Swing Lids

The SRB-108 powder-coated recycling bin is produced in 2-, 3-, 4-, and 5-compartment configurations, all sharing a 33 cm depth and 82 cm height. Length scales with compartment count from 64 cm to 154 cm. The body is fabricated from DKP cold-rolled steel finished with electrostatic powder coating. Each compartment carries an oval swing lid that rotates fully through 360 degrees over its opening.

The SRB-108 is a freestanding curved-edge recycling unit with one rotating swing lid per compartment. Mobility wheels are fitted to the base, and color is matched per project to any RAL code. The front face carries category labels and color-coded markings for paper, glass, plastic, and metal streams.

Powder-Coated Recycling Unit Configurations and Materials

Compartment Variants

The SRB-108 is offered in four configurations: 2 compartments (64 cm length), 3 compartments (94 cm), 4 compartments (124 cm), and 5 compartments (154 cm). Depth and height remain fixed at 33 cm and 82 cm across all variants.

Material Construction

The outer housing is fabricated from DKP cold-rolled steel and finished with electrostatic powder coating. Edges of the body are radius-formed rather than squared, producing curved corners along the cylindrical profile. The swing lids are produced from matching DKP material.

Surface Treatment and Color Customization

The DKP housing receives an electrostatic powder coating applied to the cleaned and pre-treated body. Color is specified per project; any standard RAL code can be matched.

Rotating Swing Lids and Mobility

Each compartment is fitted with an oval swing lid mounted on a pivot axis spanning the opening. The lid rotates fully through 360 degrees, allowing waste to be deposited from either direction and returning to the resting position after release. Mobility wheels are fitted to the base, allowing the unit to be repositioned without lifting.
